Omron E5AN User Manual

58
Setting Output Specifications Section 3-5
Auxiliary Output
Opening or Closing in
Alarm
• When “close in alarm” is set, the status of the auxiliary output is output
unchanged. When “open in alarm” is set, the status of the auxiliary output
function is reversed before being output.
• Each auxiliary output can be set independently.
• These settings are made in the Auxiliary Output 1 to 3 Open in Alarm
parameters (advanced function setting level).
• The default is n-o: Close in Alarm.
Advanced Function Setting Level
6. Select the Control Output 1 Assignment parameter by pressing the M
Key.
7. Press the U or D Key to set o.
(The default is o.)
Advanced Function Setting Level
8. Select the Control Output 2 Assignment parameter by pressing the M
Key.
9. Press the U or D Key to set c-o.
(When h-c is selected for the Standard or Heating/Cooling parameter,
the setting will be c-o.)
Advanced Function Setting Level
10. Select the Auxiliary Output 1 Assignment parameter by pressing the M
Key.
11. Press the U or D Key to set alm1.
(The default is alm1.)
Advanced Function Setting Level
12. Select the Auxiliary Output 2 Assignment parameter by pressing the M
Key.
13. Press the U or D Key to set alm2.
(The default is alm2.)
Initial Setting Level
14. Press the O Key for at least one second to move from the advanced
function setting level to the initial setting level.
Operation Level
15. Press the O Key for at least one second to move from the initial setting
level to the operation level.
out1
o
Control Output
1 Assignment
out1
o
out2
c-o
Control Output
2 Assignment
out2
c-o
sub1
alm1
Auxiliary Output
1 Assignment
sub1
alm1
sub2
alm2
Auxiliary Output
2 Assignment
sub2
alm2
in-t
5
Input Type
C
25
100
PV/SP
