5 Advanced Operations
5 - 58
E5@C-T Digital Temperature Controllers User’s Manual (H185)
• If an advance operation is executed, a time equivalent to the set program time will be considered
to have elapsed. For example, if an advance operation is executed before the ON time elapses in
the above figure, the output remains ON from the start of the next segment until the OFF time has
elapsed.
• The time signals will turn OFF at the following times.
• During a reset
•
If one program execution has been completed when program repetitions or a program link has been
set
• If the Operation End Operation parameter is set to Fixed SP Mode and the program ends
• When the ON time and the OFF time are the same
• The time signal timer stops during hold, wait, and autotuning operations.
z Related Parameters
*Refer to 6-10 Advanced Function Setting Level for details on assigning auxiliary outputs and control outputs.
Parameter
name
Display Setting range Default Level
Time Signal 1
and 2 Set
Segment
ts1s
ts2s
0 to 31 (number of segment for time
signal)
0
Program Setting
Level
Time Signal 1
and 2 ON Time
on1
on2
0.00 to 99.59, Hours.minutes or
minutes.seconds
0.00
Program Setting
Level
Time Signal 1
and 2 OFF
Time
of1
of2
0.00 to 99.59, Hours and minutes, or
minutes and seconds
0.00
Program Setting
Level
Auxiliary
Output 1 to 4
Assignment or
Control Output
1 to 2
Assignment
sub1
sub2
sub3
sub4
out1
out2
ts1 or ts2
Auxiliary Output
1 Assignment:
alm1*
Auxiliary Output
2 Assignment:
alm2*
Auxiliary Output
3 Assignment:
alm3*
Auxiliary Output
4 Assignment:
alm4*
Control Output 1
Assignment: o*
Control Output 2
Assignment:
none*
Advanced
Function Setting
Level
