165
Appendix A
Initial Setting Level
Parameters Characters Setting (monitor) value Display Default Unit Set value
Input Type in-t Univer-
sal-input
0: Pt100
1: Pt100
2: Pt100
3: JPt100
4: JPt100
5None
5: K
6: K
7: J
8: J
9: T
10: T
11: E
12: L
13: U
14: U
15: N
16: R
17: S
18: B
19: 10 to 70°C
20: 60 to 120°C
21: 115 to 165°C
22: 140 to 260°C
23: 0 to 50 mV
Analog
input
0: 4 to 20 mA
1: 0 to 20 mA
2: 1 to 5 V
3: 0 to 5 V
4: 0 to 10 V
0None
Scaling Upper Limit in-h Scaling lower limit + 1 to
9,999
100 None
Scaling Lower Limit in-l −1,999 to scaling upper limit
−1
0None
Decimal Point dp Universal-input: 0 to 1 0 None
Analog input: 0 to 3 0 None
Temperature Unit d-u °C, °F c, f °CNone
SP Upper Limit sl-h SP lower limit + 1 to input
range upper limit (tempera-
ture)
1300 EU
SP lower limit + 1 to scaling
upper limit (analog)
100
SP Lower Limit sl-l Input range lower limit to SP
upper limit − 1 (temperature)
−200 EU
Scaling lower limit to SP
upper limit − 1 (analog)
0
PID ON/OFF intl ON/OFF 2-PID onof, pid ON/OFF None
Standard or Heating/
Cooling
s-hc Standard or heating/cooling stnd, h-c Standa
rd None
ST st OFF, ON off, on ON None
Control Period
(Heating)
cp 0.5 or 1 to 99 0.5, 1 to 99 20 Second
Control Period (Cool-
ing)
c-cp 0.5 or 1 to 99 0.5, 1 to 99 20 Second
Direct/Reverse
Operation
orev Reverse operation, direct
operation
or-r, or-d Reverse
operation
None
