166
Appendix A
Alarm 1 Type alt1 0: Alarm function OFF
1: Upper and lower-limit
alarm
2: Upper-limit alarm
3: Lower-limit alarm
4: Upper and lower-limit
range alarm
5: Upper and lower-limit
alarm with standby
sequence
6: Upper-limit alarm with
standby sequence
7: Lower-limit alarm with
standby sequence
8: Absolute-value upper-limit
alarm
9: Absolute-value lower-limit
alarm
10: Absolute-value upper-limit
alarm with standby
sequence
11: Absolute-value lower-limit
alarm with standby
sequence
12: LBA (Loop Break Alarm)
2None
Alarm 2 Type alt2 0: Alarm function OFF
1: Upper and lower-limit
alarm
2: Upper-limit alarm
3: Lower-limit alarm
4: Upper and lower-limit
range alarm
5: Upper and lower-limit
alarm with standby
sequence
6: Upper-limit alarm with
standby sequence
7: Lower-limit alarm with
standby sequence
8: Absolute-value upper-limit
alarm
9: Absolute-value lower-limit
alarm
10: Absolute-value upper-limit
alarm with standby
sequence
11: Absolute-value lower-limit
alarm with standby
sequence
2None
Alarm 3 Type alt3 Same settings as the alarm 2
type
2None
Transfer Output
Type
tr-t OFF: OFF
SP: Set point
SP-M: Set point during SP
ramp
PV: Process value
MV: Manipulated variable
(heating)
C-MV: Manipulated variable
(cooling)
off
sp
sp-m
pv
mv
c-mv
OFF None
Transfer Output
Upper Limit
tr-h See note. See note. See note.
Transfer Output
Lower Limit
tr-l See note. See note. See note.
Parameters Characters Setting (monitor) value Display Default Unit Set value
