167
Note
(1) Initialized when the transfer output type is changed.
Initialized if the input type, temperature unit, scaling upper/lower limit, or SP upper/
lower limit is changed when the transfer output type is SP, ramp SP, or PV.
(When initialized by the initializing settings, it is initialized to 100.0/0.0.)
Transfer output
type
Setting (monitor) range Default (transfer output
upper/lower limits) (See
note 1)
Unit
Set point SP lower limit to SP upper limit SP upper limit/lower limit EU
Set point during SP
ramp
SP lower limit to SP upper limit SP upper limit/lower limit EU
PV Temperature: Sensor setting
range lower limit to sensor set-
ting range upper limit
Sensor setting range upper/
lower limit
EU
Analog: Scaling lower limit to
scaling upper limit
Scaling upper/lower limit EU
MV monitor (heating) Standard: −5.0 to 105.0
Heating/cooling: 0.0 to 105.0
100.0/0.0 %
MV monitor (cooling) 0.0 to 105.0 100.0/0.0 %
