5 - 13
5 Communications Data for Modbus
E5@C Digital Temperature Controllers Communications Manual (H175)
5-1 Variable Area (Setting Range) List
5
*1 Selection is possible only with the E5DC and E5GC. (The D5DC must be manufactured in July 2014 or later (version 2.2
or higher).)
*2 You can use this parameter only with the E5EC-PR@-8@@ or E5AC-PR@-8@@. (The Digital Controller must be
manufactured in August 2014 or later (version 2.2 or higher).)
0F1C 2F0E Auxiliary Output 2 Open
in Alarm
H'00000000 (0): Close in alarm
H'00000001 (1): Open in alarm
Advanced
function
setting
0F1E 2F0F Auxiliary Output 3 Open
in Alarm
H'00000000 (0): Close in alarm
H'00000001 (1): Open in alarm
0F20 2F10 Auxiliary Output 4 Open
in Alarm
H'00000000 (0): Close in alarm
H'00000001 (1): Open in alarm
0F22 2F11 Alarm 1 ON delay H'00000000 to H'000003E7 (0 to 999)
0F24 2F12 Alarm 2 ON delay H'00000000 to H'000003E7 (0 to 999)
0F26 2F13 Alarm 3 ON delay H'00000000 to H'000003E7 (0 to 999)
0F28 2F14 Alarm 4 ON delay H'00000000 to H'000003E7 (0 to 999)
0F2A 2F15 Alarm 1 OFF delay H'00000000 to H'000003E7 (0 to 999)
0F2C 2F16 Alarm 2 OFF delay H'00000000 to H'000003E7 (0 to 999)
0F2E 2F17 Alarm 3 OFF delay H'00000000 to H'000003E7 (0 to 999)
0F30 2F18 Alarm 4 OFF delay H'00000000 to H'000003E7 (0 to 999)
1000 3000 PV/SP No. 1 Display
Selection
H'00000000 (0):Nothing displayed.
H'00000001 (1):PV/SP
H'00000002 (2):PV
H'00000003 (3):PV/SP (character display)
H'00000004 (4):PV/SP/MV
H'00000005 (5):PV/SP/Multi-SP No.
H'00000006 (6):PV/SP/Soak time remain
H'00000007 (7):PV/SP/Ramp SP
H'00000008 (8):PV/SP/Alarm value 1
1002 3001 MV Display Selection H'00000000 (0): MV (heating)
H'00000001 (1): MV (cooling)
1006 3003 Automatic Display Return
Time
H'00000000 (0): OFF
H'00000001 to H'00000063 (1 to 99)
1008 3004 Display Refresh Period H'00000000 (0):OFF
H'00000001 (1): 0.25
H'00000002 (2): 0.5
H'00000003 (3): 1.0
1010 3008 PV/SP No. 2 Display
Selection
H'00000000 to H'00000008 (0 to 8)
Note: Same as PV/SP No. 1 Display Selection.
1012 3009 Valve Opening Monitor
Selection
*2
H'00000000 (0): Measured opening
H'00000001 (1): Estimated opening
Initial setting
1014 300A Display Brightness H'00000001 to H'00000003 (1 to 3) Advanced
function
setting
1016 300B MV Display H'00000000 (0): OFF
H'00000001 (1): ON
1018 300C Move to Protect Level
Time
H'00000001 to H'0000001E (1 to 30)
101E 300F Auto/Manual Select
Addition
H'00000000 (0): OFF
H'00000001 (1): ON
1022 3011 PV Status Display
Function
H'00000000 (0): OFF
H'00000001 (1): Manual
H'00000002 (2): Stop
H'00000003 (3): Alarm 1
H'00000004 (4): Alarm 2
H'00000005 (5): Alarm 3
H'00000006 (6): Alarm 4
H'00000007 (7): Alarm 1 to 4 OR status
H'00000008 (8): Heater alarm
H'00000009 (9): Status display message
*1
1024 3012 SV Status Display
Function
H'00000000 to H'00000009 (0 to 9)
Note: Same as for PV Status Display Function.
Address
Parameter name Setting (monitor) value Level
Four-byte
mode
Two-byte
mode
