Communications Setting Level
Display condition: The Protocol Setting parameter must be set to fins, mcp4, or fxp4.
Note: 1 The First Address Upper Word and First Address Lower Word parameters together specify the first
address.
Example: (1) If the first address of the PLC is 123456, set the First Address Upper Word parameter to
12 and the First Address Lower Word parameter to 3456 in the E5@C.
(2) If you use an area labeled with “*1,” convert the first address of the PLC (hexadecimal) to
a decimal number and set the decimal value in the E5@C.
If the first address of the PLC is 12345, set the First Address Upper Word parameter to 7
and the First Address Lower Word parameter to 4565 in the E5@C.
2 Set the same first address in all of the E5@C Controllers (e.g., set the same value as the value that is set
for the E5@C with communications unit number 0).
Applicable PLC Memory Addresses
Parameter name Displayed characters Setting range Default
Area area • When Protocol Setting Parameter Is Set to FINS 0
0: DM
1: EM0
2: EM1
3: EM2
4: EM3
5: EM4
6: EM5
7: EM6
8: EM7
9: EM8
10: EM9
11: EMA
12: EMB
13: EMC
14: EMD
15: EME
16: EMF
17: EM10
18: EM11
19: EM12
20: EM13
21: EM14
22: EM15
23: EM16
24: EM17
25: EM18
• When Protocol Setting Parameter Is Set to MCP4
0: D data registers
1: W link registers
*1
2: R file registers
3: ZR file registers
*1
4 to 25: D data registers
• When Protocol Setting Parameter Is Set to FXP4
0: D data registers (DM
data memory registers)
1: None (W link registers)
*1
2: R expansion registers
(FM file registers)
3 to 25: Do not use.
Device names in parentheses are for Keyence
KV-series PLCs.
First Address Upper
Word
adrh 0 to 99 0
First Address Lower
Word
adrl 0 to 9999 0
Protocol setting Area
Applicable address range
*2
Host Link (FINS) DM 0 to 32767
EM0 to EM18
MC protocol (format 4) D data registers 0 to 12287
W link registers 0 to 8191 (1FFF hex)
R file registers 0 to 32767
ZR file registers 0 to 999999 (F423F hex)
Dedicated protocol (format 4) D data registers
DM data memory registers
*1
0 to 7999
W link registers
*1
0 to 16383 (3FFF hex)
R expansion registers
FM file registers
*1
0 to 9999
To Next Page
