7 - 5
7 Component Communications
E5@C Digital Temperature Controllers Communications Manual (H175)
7-1 Component Communications
7
7-1-3 E5@C Setup
SP Calculations
The set point (SP) of a slave can be calculated from the set point of the master as shown below. The
slave performs the calculation only during operation. The value is not written to the slave if it exceeds
the set point limiter.
During operation: Slave SP = Master SP × SP Slope + SP Offset
When stopped: Slave SP = Master SP
Communications Setting Level
Display condition: The Protocol Setting parameter must be set to cmp and the Communications Unit
No. parameter must not be set to 0 (0 = master).
* The decimal point position depends on the Decimal Point parameter setting.
Parameter name
Displayed
characters
Setting range Unit Default
SP Slope sps 0.001 to 9.999 None 1.000
SP Offset spos Temperature input: −199.9 to 999.9
Analog input: −1,999 to 9,999*
EU 0.0
To Next Page
