Omron E5EC Communications Manual

3 - 3
3 Communications Data for CompoWay/F
E5@C Digital Temperature Controllers Communications Manual (H175)
3-1 Variable Area (Setting Range) List
3
Note: The alarm function can also be used in Digital Temperature Controllers that do not have any auxiliary
outputs. In this case, confirm alarm occurrences via the status data.
Variable
type
Address Parameter name Setting (monitor) value Level
C1 (81) 0000 Operation/Adjustm
ent Protect
H'00000000 (0): No restrictions in operation and
adjustment levels
H'00000001 (1): Move to adjustment level is
prohibited.
H'00000002 (2): Display and change of only "PV"
and "PV/SP" parameters is allowed.
H'00000003 (3): Display of only "PV" and "PV/SP"
parameters is allowed.
Protect
C1 (81) 0001 Initial
Setting/Communic
ations Protect
H'00000000 (0): Move to initial
setting/communications setting
level is allowed. (Move to advanced
function setting level is displayed.)
H'00000001 (1): Move to initial
setting/communications setting
level is allowed. (Move to advanced
function setting level is not
displayed.)
H'00000002 (2): Move to initial
setting/communications setting
level is prohibited.
C1 (81) 0002 Setting Change
Protect
H'00000000 (0): OFF (Changing of setup on
Controller display is allowed.)
H'00000001 (1): ON (Changing of setup on
Controller display is prohibited.)
C1 (81) 0003 Set Point SP lower limit to SP upper limit Operation
C1 (81) 0004 Alarm Value 1 H'FFFFF831 to H'0000270F (−1999 to 9999)
C1 (81) 0005 Alarm Value Upper
Limit 1
H'FFFFF831 to H'0000270F (−1999 to 9999)
C1 (81) 0006 Alarm Value Lower
Limit 1
H'FFFFF831 to H'0000270F (−1999 to 9999)
C1 (81) 0007 Alarm Value 2 H'FFFFF831 to H'0000270F (−1999 to 9999)
C1 (81) 0008 Alarm Value Upper
Limit 2
H'FFFFF831 to H'0000270F (−1999 to 9999)
C1 (81) 0009 Alarm Value Lower
Limit 2
H'FFFFF831 to H'0000270F (−1999 to 9999)
C1 (81) 000A Alarm Value 3 H'FFFFF831 to H'0000270F (−1999 to 9999)
C1 (81) 000B Alarm Value Upper
Limit 3
H'FFFFF831 to H'0000270F (−1999 to 9999)
C1 (81) 000C Alarm Value Lower
Limit 3
H'FFFFF831 to H'0000270F (−1999 to 9999)
C1 (81) 000D Heater Burnout
Detection 1
H'00000000 to H'000001F4 (0.0 to 50.0) Adjustment
C1 (81) 000E SP 0 SP lower limit to SP upper limit
C1 (81) 000F SP 1 SP lower limit to SP upper limit
C1 (81) 0010 SP 2 SP lower limit to SP upper limit
C1 (81) 0011 SP 3 SP lower limit to SP upper limit
C1 (81) 0012 Process Value
Input Shift
H'FFFFF831 to H'0000270F (−1999 to 9999)
C1 (81) 0013 PV Input Slope
Coefficient
H'00000001 to H'0000270F (0.001 to 9.999)
C1 (81) 0015 Proportional Band H'0000001 to H'0000270F (0.1 to 999.9)
