3 Communications Data for CompoWay/F
3 - 8
E5@C Digital Temperature Controllers Communications Manual (H175)
Variable
type
Address
Parameter
name
Setting (monitor) value Level
C3 (83) 0000 Input Type H'00000000 (0): Pt (−200 to 850°C/−300 to 1500°F)
H'00000001 (1): Pt (−199.9 to 500.0°C/−199.9 to
900.0°F)
H'00000002 (2): Pt (0.0 to 100.0°C/0.0 to 210.0°F)
H'00000003 (3): JPt (−199.9 to 500.0°C/−199.9 to
900.0°F)
H'00000004 (4): JPt (0.0 to 100.0°C/0.0 to 210.0°F)
H'00000005 (5): K (−200 to 1300°C/−300 to 2300°F)
H'00000006 (6): K (−20.0 to 500.0°C/0.0 to 900.0°F)
H'00000007 (7): J (−100 to 850°C/−100 to 1500°F)
H'00000008 (8): J (−20.0 to 400.0°C/0.0 to 750.0°F)
H'00000009 (9): T (−200 to 400°C/−300 to 700°F)
H'0000000A (10): T (−199.9 to 400.0°C/−199.9 to
700.0°F)
H'0000000B (11): E (−200 to 600°C/−300 to 1100°F)
H'0000000C (12): L (−100 to 850°C/−100 to 1500°F)
H'0000000D (13): U (−200 to 400°C/−300 to 700°F)
H'0000000E (14): U (−199.9 to 400.0°C/−199.9 to
700.0°F)
H'0000000F (15): N (−200 to 1300
°C/−300 to 2300
°F)
H'00000010 (16): R (0 to 1700°C/0 to 3000°F)
H'00000011 (17): S (0 to 1700°C/0 to 3000°F)
H'00000012 (18): B (100 to 1800°C/300 to 3200°F)
H'00000013 (19): W (0 to 2300°C/0 to 3200°F)
H'00000014 (20): PL II (0 to 1300°C/0 to 2300°F)
H'00000015 (21): Infrared temperature sensor (K
140°F/60°C)
H'00000016 (22): Infrared temperature sensor (K
240°F/120°C)
H'00000017 (23): Infrared temperature sensor (K
280°F/140°C)
H'00000018 (24): Infrared temperature sensor (K
440°F/220°C)
H'00000019 (25): 4 to 20 mA
H'0000001A (26): 0 to 20 mA
H'0000001B (27): 1 to 5 V
H'0000001C (28): 0 to 5 V
H'0000001D (29): 0 to 10 V
H'0000001E (30): 0 to 50 mV*
* Selection is possible only for E5CC-U Controllers and
only if they are manufactured in May 2014 or later
(version 2.2).
Initial
setting
C3 (83) 0001 Scaling Upper
Limit
Scaling lower limit + 1 to H'0000270F (Scaling lower limit +
1 to 9,999)
C3 (83) 0002 Scaling Lower
Limit
H'FFFFF831 to Scaling upper limit − 1 (−1999 to Scaling
upper limit − 1)
C3 (83) 0003 Decimal Point H'00000000 to 00000003 (0 to 3)
C3 (83) 0004 Temperature
Unit
H'00000000 (0): °C
H'00000001 (1): °F
C3 (83) 0005 SP Upper Limit The range of values (without decimal point) is as follows:
Temperature input: SP lower limit + 1 to Input range upper
limit
Analog input: SP lower limit + 1 to Scaling upper
limit
