3 Communications Data for CompoWay/F
3 - 12
E5@C Digital Temperature Controllers Communications Manual (H175)
Note: The alarm function can also be used in Digital Temperature Controllers that do not have any auxiliary
outputs. In this case, confirm alarm occurrences via the status data.
Variable
type
Address Parameter name Setting (monitor) value Level
C3 (83) 0020 Auxiliary Output 2
Open in Alarm
H'00000000 (0): Close in alarm
H'00000001 (1): Open in alarm
Advance
d function
setting
C3 (83) 0021 Alarm 2 Hysteresis H'00000001 to H'0000270F
(0.1 to 999.9 for temperature input)
(0.01 to 99.99 for analog input)
Initial
setting
C3 (83) 0022 Auxiliary Output 3
Open in Alarm
H'00000000 (0): Close in alarm
H'00000001 (1): Open in alarm
Advance
d function
setting
C3 (83) 0023 Alarm 3 Hysteresis H'00000001 to H'0000270F
(0.1 to 999.9 for temperature input)
(0.01 to 99.99 for analog input)
Initial
setting
C3 (83) 0024 HB ON/OFF H'00000000 (0): OFF
H'00000001 (1): ON
Advance
d function
setting
C3 (83) 0025 Heater Burnout
Latch
H'00000000 (0): OFF
H'00000001 (1): ON
C3 (83) 0026 Heater Burnout
Hysteresis
H'00000001 to H'000001F4 (0.1 to 50.0)
C3 (83) 0027 ST Stable Range H'00000001 to H'0000270F (0.1 to 999.9)
C3 (83) 0028 α H'00000000 to H'00000064 (0.00 to 1.00)
C3 (83) 002B Input Digital Filter H'00000000 to H'0000270F (0.0 to 999.9)
C3 (83) 002C PV/SP No. 2
Display Selection
H'00000000 (0): Nothing displayed.
H'00000001 (1): PV/SP
H'00000002 (2): PV
H'00000003 (3): PV/SP (character display)
H'00000004 (4): PV/SP/MV
H'00000005 (5): PV/SP/Multi-SP No.
H'00000006 (6): PV/SP/Soak time remain
H'00000007 (7): PV/SP/Internal SP (ramp SP)
H'00000008 (8): PV/SP/Alarm value 1
C3 (83) 002D MV Display H'00000000 (0): OFF
H'00000001 (1): ON
C3 (83) 002E Automatic Display
Return Time
H'00000000 (0): OFF
H'00000001 to H'00000063 (1 to 99)
C3 (83) 002F Alarm 1 Latch H'00000000 (0): OFF
H'00000001 (1): ON
C3 (83) 0030 Alarm 2 Latch H'00000000 (0): OFF
H'00000001 (1): ON
C3 (83) 0031 Alarm 3 Latch H'00000000 (0): OFF
H'00000001 (1): ON
C3 (83) 0032 Move to Protect
Level Time
H'00000001 to H'0000001E (1 to 30)
C3 (83) 0033 Integrated Alarm
Assignment
H'00000000 to H'000000FF (0 to 255)
C3 (83) 0034 Cold Junction
Compensation
Method
H'00000000 (0): OFF
H'00000001 (1): ON
