Omron E5EC Communications Manual

3 Communications Data for CompoWay/F
3 - 22
E5@C Digital Temperature Controllers Communications Manual (H175)
C3 (83) 00CA Simple Transfer
Output 1 Upper
Limit
*1
H'FFFFF831 to H'0000270F (−1999 to 9999)
Initial setting
C3 (83) 00CB Simple Transfer
Output 1 Lower
Limit
*1
H'FFFFF831 to H'0000270F (−1999 to 9999)
C3 (83) 00CC FB Moving Average
Count
*2
H'00000000 (0): OFF
H'00000001 (1): 2 times
H'00000002 (2): 4 times
H'00000003 (3): 8 times
H'00000004 (4): 16 times
H'00000005 (5): 32 times
Advanced
function setting
C3 (83) 00CD Valve Opening
Monitor Selection
*2
H'00000000 (0): Measured opening
H'00000001 (1): Estimated opening
Initial setting
*1 Selection is possible only with the E5CC-U, E5DC, and E5GC and only when there is a control output that
is a linear current output.
(The E5CC-U must be manufactured in May 2014 or later (version 2.2 or higher) and the E5DC must be
manufactured in July 2014 or later (version 2.2 or higher).)
*2 You can use this parameter only with the E5EC-PR@-8@@ or E5AC-PR@-8@@. (The Digital Controller
must be manufactured in August 2014 or later (version 2.2 or higher).)
Variable
type
Address Parameter name Setting (monitor) value Level

Omron E5EC Specifications

General

Mounting Type	Panel Mount
Display Resolution	0.1°C or 1°C
Control Method	ON/OFF
Input Type	Thermocouple, RTD, Analog voltage
Supply Voltage	100 to 240 VAC
Output Type	Relay, Voltage, Current
Size	48 x 96 mm
Control Output	Relay, Voltage, Current
Alarm Output	Relay
Communication	RS-485
Ambient Operating Temperature	-10 to 55°C
Ambient Operating Humidity	25 to 85% RH
Protection Rating	IP20
