Omron E5EC User Manual

6 Parameters
6 - 16
E5@C Digital Temperature Controllers User’s Manual (H174)
This parameter is used to monitor the manipulated variable for the heating control output during opera-
tion.
This parameter is used to monitor the manipulated variable for the cooling control output during opera-
tion.
o
MV Monitor (Heating) The MV Display parameter must be set to ON.
• During standard control, the manipulated variable is monitored. During heating/cooling
control, the manipulated variables on the control output (heating) is monitored.
• The default is OFF and the manipulated variable is not displayed.
 Related Parameters
MV Display (Advanced Function Setting Level): Page 6-70
c-o
MV Monitor (Cooling)
The control system must be set to heating/cooling
control.
The MV Display parameter must be set to ON.
• During heating/cooling control, the manipulated variable on the control output (cooling) is
monitored.
• The default is OFF and the manipulated variable is not displayed.
 Related Parameters
Standard or Heating/Cooling (Initial Setting Level): Page 6-46
MV Display (Advanced Function Setting Level): Page 6-70
Function
Monitor
Control Monitor range Unit
Standard −5.0 to 105.0 %
Heating/cooling 0.0 to 105.0 %
See
See
Function
Monitor
Control Monitor range Unit
Heating/cooling 0.0 to 105.0 %
See
See

Omron E5EC Specifications

General

Mounting Type	Panel Mount
Display Resolution	0.1°C or 1°C
Control Method	ON/OFF
Input Type	Thermocouple, RTD, Analog voltage
Supply Voltage	100 to 240 VAC
Output Type	Relay, Voltage, Current
Size	48 x 96 mm
Control Output	Relay, Voltage, Current
Alarm Output	Relay
Communication	RS-485
Ambient Operating Temperature	-10 to 55°C
Ambient Operating Humidity	25 to 85% RH
Protection Rating	IP20
