6 Parameters
6 - 70
E5@C Digital Temperature Controllers User’s Manual (H174)
o-dp
MV Display A Standard Model must be used.
This parameter is used to display the manipulated variable (MV).
The manipulated variable is displayed when the MV Monitor (Heating) and MV Monitor
(Cooling) parameters are set to ON, and not displayed when these parameters are set to
OFF.
 Related Parameters
MV Monitor (Heating) (Operation Level): Page 6-16
MV Monitor (Cooling) (Operation Level): Page 6-16
ret
Automatic Display Return Time
• In the Operation Level, Adjustment Level, or Monitor/Setting Item Level, the display
automatically returns to the PV/SP if there are no key operations for the time set for this
parameter.
• The automatic display return time is disabled when the parameter is set to OFF. (In that
case, the display will not be automatically switched.)
brgt
Display Brightness
This parameter sets the display brightness to one of three levels. Adjust the level if the dis-
play is too bright.
Function
Setting
Setting range Default
on: Displayed, off: Not displayed off
See
See
Function
Setting
Setting range Unit Default
OFF, 1 to 99 Seconds off
000
Function
Setting
Setting range Default
1 (dark) to 3 (bright) 3

Omron E5EC Specifications

General

Mounting Type	Panel Mount
Display Resolution	0.1°C or 1°C
Control Method	ON/OFF
Input Type	Thermocouple, RTD, Analog voltage
Supply Voltage	100 to 240 VAC
Output Type	Relay, Voltage, Current
Size	48 x 96 mm
Control Output	Relay, Voltage, Current
Alarm Output	Relay
Communication	RS-485
Ambient Operating Temperature	-10 to 55°C
Ambient Operating Humidity	25 to 85% RH
Protection Rating	IP20
