57
Screw-less Clamp Terminals Section 4-2
Outputs
Dimensions
NC0123456789101112131415NC
V V0V1V2V3V4V5V6V7V8V9V10V11V12V13V14V15V
GGGGGGGGGGGGGGGGGG
X
VX
G
X
VX
G
(IEC colors)
(Previous
colors)
Blue
(Black)
Brown
(Red)
Black
(White)
3-wire sensors
(photoelectric or proximity sensors)
Brown
(White)
Blue
(Black)
(IEC colors)
(Previous
colors)
2-wire sensors
(2-wire proximity sensors)
X: 0 to 15
