34
Overview of System Startup Procedure Section 2-1
Depending on the status of the connected PLC, a window like the one shown
below may be displayed.
After the connection settings have been downloaded, a message like the one
shown below will be displayed. Click the OK Button.
2-1-6 Edit Connection Dialog Boxes
The following figures show examples of connection settings for various Ether-
Net/IP Slave Units.
Click the Yes Button.
Click the Download after
changed to Program
mode Button.
Click the Yes Button.
To Next Page
