7 - 31
7 Digital I/O Slave Unit
GX-series EtherCAT Slave Unit User’s Manual
7-4 Specifications for Each Slave Unit
7
7-4-5 3-tier Terminal Block Type 16-point Input Slave Unit GX-ID1612/ID1622
 GX-ID1612 (NPN)
 GX-ID1622 (PNP)
Wiring diagram
NPN output 3-wire sensor
(Photoelectric sensor,
proximity sensor)
2-wire sensor
(Limit switch, etc.)
Blue (black) Black (white)
Brown (red) Brown (white) Blue (black)
NC
NC
89
0123
4567
V1 V1 V1 V1 V1 V1 V1 V1
G1 G1 G1 G1 G1 G1 G1 G1
V1
G1
10 11
12 13 14 15
V2 V2 V2 V2 V2 V2 V2 V2 V2
G2 G2 G2 G2 G2 G2 G2 G2 G2
I/O power supply
(24 VDC)
PNP output 3-wire sensor
(Photoelectric sensor,
proximity sensor)
2-wire sensor
(Limit switch, etc.)
Blue (black) Black (white)
Brown (red) Brown (white) Blue (black)
NC
NC
89
0123
4567
V1 V1 V1 V1 V1 V1 V1 V1
G1 G1 G1 G1 G1 G1 G1 G1
V1
G1
10 11
12 13 14 15
V2 V2 V2 V2 V2 V2 V2 V2 V2
G2 G2 G2 G2 G2 G2 G2 G2 G2
I/O power supply
(24 VDC)
