7 Digital I/O Slave Unit

GX-series EtherCAT Slave Unit User’s Manual

7-5 Mounting Dimensions

7-5-1 2-tier Terminal Block Type

7-5 Mounting Dimensions

The mounting dimensions of a Digital I/O Slave Unit are shown below.

 GX-ID1611/ID1621/OD1611/OD1621

 GX-OC1601

7-5-1 2-tier Terminal Block Type

73.9

57.1

135

3.14

(mm)

74.4

57.6

160

3.14

(mm)

Default Chapter7
