7 Digital I/O Slave Unit

7 - 76

GX-series EtherCAT Slave Unit User’s Manual

 GX-MD1611/MD1621

7-5-2 3-tier Terminal Block Type

73.9

57.1

50

135

52

3.14

(mm)

10.1

93.5

200

52

503.14

68.9

(mm)
