10 - 11
10 IO-Link Master Unit
GX-series EtherCAT Slave Unit User’s Manual
10-4 Specifications
10
10-4-1 Specifications
Unit Specifications
The specifications for the GX-ILM08C are given below.
Item Specification
Unit name IO-Link Master Unit
Model GX-ILM08C
Number of IO-Link ports 8
Communications
specifications
Baud rate
COM1: 4.8 kbps
COM2: 38.4 kbps
COM3: 230.4 kbps
Device power
supply
*1
in IO-Link
Mode or SIO (DI)
Mode
Rated voltage 24 VDC (20.4 to 26.4 VDC)
Maximum load
current
0.2 A/port
Short-circuit
protection
Yes
Digital inputs (in SIO
(DI) Mode)
Internal I/O common PNP
Rated voltage 24 VDC (20.4 to 26.4 VDC)
Input current 5 mA typical (at 24 VDC)
ON voltage/ON
current
15 VDC min., 5 mA min.
OFF voltage 5 VDC max.
Input filter time
No filter, 0.25 ms, 0.5 ms, 1 ms (default), 2 ms, 4 ms, 8 ms, 16
ms, 32 ms, 64 ms, 128 ms, or 256 ms
Digital outputs (in
SIO (DIO) Mode)
Internal I/O common PNP
Output type Push-pull
Rated voltage 24 VDC (20.4 to 26.4 VDC)
Maximum load
current
0.3 A/port
Short-circuit
protection
Provided.
Leakage current 0.1 mA max.
Residual voltage 1.5 V max.
Digital inputs for Pin
2 (in IO-Link Mode)
Internal I/O common PNP
Rated voltage 24 VDC (20.4 to 26.4 VDC)
Input current 2 mA (24 VDC)
ON voltage/ON
current
15 VDC min., 2 mA min.
OFF voltage 5 VDC max.
Input filter time
No filter, 0.25 ms, 0.5 ms, 1 ms (default), 2 ms, 4 ms, 8 ms, 16
ms, 32 ms, 64 ms, 128 ms, or 256 ms
Cable specifications
Cable type Unshielded
Cable length 20 m max.
Electrostatic
capacity between
lines
3 nF max.
Loop resistance 6 Ω max.
Dimensions
175 × 32.8 × 60 mm (W×H×D) (The height is 49.1 mm when
the connectors are included.)
Isolation method Photocoupler isolation
I/O power supply method Supplied from the power supply connector.
Unit power supply current consumption 60 mA
I/O power supply current consumption 100 mA
Weight 430 g
