A Appendix
A - 56
GX-series EtherCAT Slave Unit User’s Manual
The contents of Error Status for Ports 5 and 6 are given below. The status can be accessed either as
WORD data or BOOL data.
The contents of Error Status for Ports 7 and 8 are given below. The status can be accessed either as
WORD data or BOOL data.
3004 hex Port7_8 I/O Port Error Status
Sub-index 0: Number of entries
Range: − Unit: − Default: 01 hex Attribute: −
Size: 1 byte (U8) Access: RO PDO map: Not possible
Sub-index 1: Port7_8 I/O Port Error Status
Range: − Unit: − Default: 0000 hex Attribute: −
Size: 2 bytes (U16) Access: RO PDO map: Not possible
Bit Meaning
Default
value
Data range Unit Data type Access
I/O allo-
cation
Data
attribute
0 Port 5 IO-Link Communications
Error Flag
FALSE FALSE/TRUE --- BOOL RO Possible ---
1 Port 5 IO Short Detected Flag FALSE FALSE/TRUE --- BOOL RO Possible ---
2 Port 5 Verification Error Flag FALSE FALSE/TRUE --- BOOL RO Possible ---
3 Port 5 Device I/O Size Error Flag FALSE FALSE/TRUE --- BOOL RO Possible ---
4 Port 5 Device Error-level Event
Flag
FALSE FALSE/TRUE --- BOOL RO Possible ---
5 Port 5 Device Warning-level Event
Flag
FALSE FALSE/TRUE --- BOOL RO Possible ---
6 Port 5 PDO Mapping Error Flag FALSE FALSE/TRUE --- BOOL RO Possible ---
8 Port 6 IO-Link Communications
Error Flag
FALSE FALSE/TRUE --- BOOL RO Possible ---
9 Port 6 IO Short Detected Flag FALSE FALSE/TRUE --- BOOL RO Possible ---
10 Port 6 Verification Error Flag FALSE FALSE/TRUE --- BOOL RO Possible ---
11 Port 6 Device I/O Size Error Flag FALSE FALSE/TRUE --- BOOL RO Possible ---
12 Port 6 Device Error-level Event
Flag
FALSE FALSE/TRUE --- BOOL RO Possible ---
13 Port 6 Device Warning-level Event
Flag
FALSE FALSE/TRUE --- BOOL RO Possible ---
14 Port 6 PDO Mapping Error Flag FALSE FALSE/TRUE --- BOOL RO Possible ---
Bit Meaning
Default
value
Data range Unit Data type Access
I/O allo-
cation
Data
attribute
0 Port 7 IO-Link Communications
Error Flag
FALSE FALSE/TRUE --- BOOL RO Possible ---
1 Port 7 IO Short Detected Flag FALSE FALSE/TRUE --- BOOL RO Possible ---
2 Port 7 Verification Error Flag FALSE FALSE/TRUE --- BOOL RO Possible ---
3 Port 7 Device I/O Size Error Flag FALSE FALSE/TRUE --- BOOL RO Possible ---
4 Port 7 Device Error-level Event
Flag
FALSE FALSE/TRUE --- BOOL RO Possible ---
5 Port 7 Device Warning-level
Event Flag
FALSE FALSE/TRUE --- BOOL RO Possible ---
6 Port 7 PDO Mapping Error Flag FALSE FALSE/TRUE --- BOOL RO Possible ---
8 Port 8 IO-Link Communications
Error Flag
FALSE FALSE/TRUE --- BOOL RO Possible ---
9 Port 8 IO Short Detected Flag FALSE FALSE/TRUE --- BOOL RO Possible ---
10 Port 8 Verification Error Flag FALSE FALSE/TRUE --- BOOL RO Possible ---
11 Port 8 Device I/O Size Error Flag FALSE FALSE/TRUE --- BOOL RO Possible ---
12 Port 8 Device Error-level Event
Flag
FALSE FALSE/TRUE --- BOOL RO Possible ---
13 Port 8 Device Warning-level
Event Flag
FALSE FALSE/TRUE --- BOOL RO Possible ---
14 Port 8 PDO Mapping Error Flag FALSE FALSE/TRUE --- BOOL RO Possible ---
