MicroHAWK F320-F / F330-F / F420-F / F430-F Smart Camera User Manual
F430-F Part Number Structure
Use this legend when defining product part numbers. Please note that not all combinations of parameters are valid. For instance, color cameras
are only available with white lighting, and 400 mm fixed focus is only available with UHD lenses. When ordering, use valid part numbers from
the tables in the Ordering Information section only.
F430-F[XXX][Y][ZZZ]-[L][C][P]
Example Part Numbers:
• F430-F081W03M-NNS: Fixed Focus at 81 mm, Wide Lens, 0.3 MP Monochrome Sensor, No Outer Light, AutoVISION Sensor
• F430-F000N12M-RRA: Autofocus, Narrow Lens, 1.2 MP Mono, Ring Light, Red, AutoVISION + Verification
• F430-F000L50C-SWV: Autofocus, Long Range Lens, 5 MP Color, Standard Light, White, AutoVISION + Verification + Visionscape
F430-F Valid Product Matrix
Key Classification Code Meaning
XXX Focus Distance (mm) 000 Autofocus – Variable Distance
050 Fixed Focus at 50 mm
064 Fixed Focus at 64 mm
081 Fixed Focus at 81 mm
102 Fixed Focus at 102 mm
133 Fixed Focus at 133 mm
190 Fixed Focus at 190 mm
300 Fixed Focus at 300 mm
400 Fixed Focus at 400 mm
Y Lens W Wide Field of View – 5.2 mm Focal Length Lens
M Medium Field of View – 7.7 mm Focal Length Lens
N Narrow Field of View – 16 mm Focal Length Lens
L Narrow 16 mm Lens – Autofocus to 1160 mm
ZZZ Sensor 03M 752 x 480 (0.3 MP) Pixel, Mono Sensor, Global Shutter
12M 1280 x 960 (1.2 MP) Pixel, Mono Sensor, Global Shutter
50C 2592 x 1944 (5 MP) Pixel, Color Sensor, Rolling Shutter
L Light Type N No Outer Light
S Standard Outer Light
R Ring Light
C Light Color N No Outer Light
RRed
WWhite
P Software License S AutoVISION Sensor (Vision Toolset Only)
A AutoVISION (Vision and Code Reading / Verification Toolsets)
V Visionscape (Full AutoVISION and Visionscape Toolsets)
Model Category Focus Type Sensor Lens Focus Distance (mm) Light License
F430-F
Monochrome
Fixed Focus
03M, 12M W, M
50, 64, 81, 102, 133,
190, 300
None, Red,
White
S, A, V
12M N 64, 400
None, Red,
White
S, A, V
Autofocus
03M W, M 50 <-> 300 Autofocus
None, Red,
White
S, A, V
12M W, M, N
50 <-> 300 (W and M)
40 <-> 150 (N)
Autofocus
None, Red,
White
S, A, V
Color
Fixed Focus 50C W, M
50, 64, 81, 102, 133,
190, 300
None, White S, A, V
Autofocus 50C W, M 50 <-> 300 Autofocus None, White S, A, V
Specialty
Ring Light
Autofocus
12M M, N
50 <-> 300 (M)
40 <-> 150 (N)
Autofocus
Red, White
(Ring)
S, A, V
Long Range
Autofocus
12M L 75 <->1160 Autofocus
None, Red,
White
S, A, V
