1 Introduction

MicroHAWK F320-F / F330-F / F420-F / F430-F Smart Camera User Manual

1-6 Part Number Structure

1-5-2 Feature Comparison

F430-F Ordering Information

Categories:

1. Fixed Focus Camera

a.) F430-F Monochrome Fixed Focus Camera

b.) F430-F Color Fixed Focus Camera

c.) F430-F 1.2 MP Monochrome Fixed Focus Camera with Narrow Lens

2. Autofocus Camera

a.) F430-F 0.3 MP Monochrome Autofocus Camera (50 – 300 mm)

b.) F430-F 1.2 MP Monochrome Autofocus Camera (50 – 300 mm for Wide and Medium Lens, 40 – 150 mm

for Narrow Lens)

c.) F430-F Color Autofocus Camera (50 - 300 mm)

d.) F430-F 1.2 MP Monochrome Autofocus Camera with Ring Light (50 – 300 mm for Medium Lens, 40 – 150

mm for Narrow Lens)

e.) F430-F 1.2 MP Monochrome Long Range Autofocus Camera (75 - 1160 mm)

1a) F430-F Monochrome Fixed Focus Camera: Valid Combinations

F430-F[XXX][Y][ZZZ]-[L][C][P]

1b) F430-F 5.0 MP Color Fixed Focus Camera: Valid Combinations

Note: 5 MP Color cameras are available with No or White light options only.

F430-F[XXX][Y]50C-[L][C][P]

Key Classification Code Meaning

XXX Focus Distance (mm) 050 Fixed Focus at 50 mm

064 Fixed Focus at 64 mm

081 Fixed Focus at 81 mm

102 Fixed Focus at 102 mm

300 Fixed Focus at 300 mm

Y Lens W Wide Field of View - 5.2 mm Focal Length Lens

M Medium Field of View – 7.7 mm Focal Length Lens

ZZZ Sensor 03M 752 x 480 (0.3 MP) Pixel, Mono Sensor, Global Shutter

12M 1280 x 960 (1.2 MP) Pixel, Mono Sensor, Global Shutter

L Light Type N No Outer Light

S Standard Outer Light

C Light Color N No Outer Light

RRed

WWhite

P Software License S AutoVISION Sensor (Vision Toolset Only)

A AutoVISION (Vision and Code Reading / Verification Toolsets)

V Visionscape (Full AutoVISION and Visionscape Toolsets)
