3 Getting Started with AutoVISION
MicroHAWK F320-F / F330-F / F420-F / F430-F Smart Camera User Manual
3-1 Setting Up a Job in AutoVISION
3
1
4
5
3
2
6
Common
(12-Pin
Plug to
12-Pin
Socket)
To Host
(Ethernet
8-Pin Plug
to RJ45)
To
Trigger
To
Power
Supply
F430-F with QX-1 Interface Device
See Appendix A, Connector Pinouts,
for the camera’s pin assignments.
