30
5-2-3 Screen Transition
Initial State
Safety Signatures
Mismatch Error
Password Entry
Registration
Completion
Safety Signature
Registered
Registration NG
Passwords not match
Passwords match
Signatures not match
Signatures match
No Authorized User Found
Authorized user not
exist
Authorized user exist
On-access
judgment on
safety
signature
