6-3-12 Safety CPU Demo Movie Screen
A safety CPU demonstration movie is played on this screen. Both Japanese and English are
available. If language other than Japanese is selected on the Menu screen, the English movie will
be played.
・Screen Layout
No
Part
Description
1
Data Display
Displays the user name who logging in.
2
Data Display
Shows the logging in user’s authority.
3
Data Display
Displays the current time.
4
Media Player
Plays the Safety CPU demo movie.
5
Button
Switches to Menu Screen.
6
Button
Stops the movie.
7
Button
Starts the movie.
8
Button
Pauses
1
2
3
4
6
5
7
7
8

Omron NA Series Specifications

General

Touch Panel	Resistive
Interfaces	USB, Ethernet, RS-232/422/485
Operating Temperature	0°C to 50°C
Power Supply	24 VDC
Protection Rating	IP65 (front panel)
Storage Temperature	-20°C to 60°C
Display Type	TFT LCD
Dimensions	Varies depending on the model
Weight	Varies depending on the model
