6-9
6 Maintenance and Troubleshooting
NB-series Programmable Terminals Startup Guide Manual(V109)
6-3 Troubleshooting
6
6-3-1 Software Trouble
8
When opening a project, what if there is a prompt: [Font not existing in the system]
For example: if attempting to open a project involving in a PC that does not incorporate
, a prompt [ does not exist] will pop up, as follows:
If this font issue is ignored, will be replaced with a font that exists in the system, eg.
UnBatang.
9
How to set the addresses of the component for displaying warnings and events, and how to
inquire warnings and events
It’s best to use the internal register of the HMI - LW for the address type of the component for
displaying warnings and events, and the address can be designated as any of the vacant
address in the project. When we record warnings and events on HMI, one page is almost
certainly not enough, then turn-page inquiring is needed to be set, thus the address in the
attributes of the component for displaying warnings and events takes effect. Take LW10 for an
example, as follows:
