A-15
Appendices
NB-series Programmable Terminals Setup Manual(V107)
A-5 List of Models
App
A-4-5 Method for fabricating the cable for
connection to PC
PLC Series Connectable to NB Series through Host Link
PLC Series Specifications
CP Series Connecting through the RS-232C optional communication board
(CP1W-CIF01) with a RS-232C cable
C200HE/HG/HX Series With a connector for RS-232C connection (switch/9-pin type)
CQM1H Series With a connector for RS-232C connection (9-pin type)
CPM1A Series Connecting through the RS-232C adaptor (CP1W-CIF01) with a RS-232C
cable
CPM2A Series With a connector for RS-232C connection (9-pin type)
CPM2C Series Connect to the branched RS-232C connector through a conversion cable
(CPM2C-CN111 type)
CS Series With a connector for RS-232C connection (9-pin type)
CJ1/CJ2 Series With a connector for RS-232C connection (9-pin type)
PLC Series connectable to NB Series through the Ethernet Unit
PLC Series Specifications
CP Series Connecting through the Ethernet optional communication board CJ1W-CIF41
CS Series Connecting through the Ethernet Unit CS1W-ETN21 or CS1W-EIP21
CJ1 Series Connecting through the Ethernet Unit CJ1W-ETN21 or CJ1W-EIP21
CJ2 Series Connecting through the Ethernet Unit CJ1W-ETN21 or CJ1W-EIP21
