Appendices
A-20
NB-series Programmable Terminals Setup Manual(V107)
RS-422A/RS-485 Communication Cable
USB Memory
It can be connected to the USB HOST port on the back of PT to perform the uploading,
downloading, project operation and storage of related data.
Models Descriptions
NB-RSEXT-2M Only applies to the COM2 port of the NB series product, when
performing communications using RS-422A/RS485, can be equipped
with this communication cable.
Instruction: When users need to carry out long-distance signal
transmission, can connect with terminal matching resistance.
How to use:
When using NB5Q/NB7W/NB10W-TW

B Unit, open RS-422A/
RS-485 communication cable RS232C Connector, use short wire to
connect PIN4 and PIN5, pay attention to wiring, do not short-circuit
with other pins except PIN4 and PIN5, when connection finished
please assembled well RS232C Connector.
When using NB3Q-TW
B Unit, turn the DIP switch SW3 of the unit
to ON.
By default, RS-422A/RS-485 communication cable do not connect
terminal resistance.
Recommended Purchasing Model Descriptions
FZ-MEM2G USB disk with 2GB capacity manufactured by OMRON
FZ-MEM8G USB disk with 8GB capacity manufactured by OMRON
NB Model
Pin NO.
1
2
3
NB
Serial Port
D-Sub
9Pin
(Female)
4
5
6
7
8
9
Signal
SDB+
SD
RD
Terminal R1
Terminal R2
RDB+
SDA-
RDA-
SG
Shell
FG
Signal
SDB+
SD
RD
RS
CS
RDB+
SDA-
RDA-
SG
FG
NB5Q /NB7W/
NB10W-TWB
NB3Q-TWB
signal wire
shield wire
Conform to UL2464, AWG28
Red
White
Black
Brown
Blue
