Omron OMNUC R88D-WT15HF

3-14
10. Analog Monitor Cable
This is the cable for connecting to the Servo Driver’s Analog Monitor Connector (CN5). It is required for
connecting analog monitor outputs to an external device (such as a measuring instrument).
Name/specifications Model Remarks
Analog Monitor Cable 1 m R88A-CMW001S Only 1-meter cables are available.
System Design and Installation
Chapter 3
