3-33
D Noise Filters for Power Supply Input
Use the following noise filters for the Servo Driver power supply
Servo Driver
dl
Noise Filter
model
Model Rated
current
Rated
voltage
Leakage current (See note.) Maker
R88D-WTA3HL to
WT01HL
SUP-P5H-EPR 5 A
250 V 0.6 mA (at 250 Vrms, 60 Hz) Okaya
Electric
Industries
R88D-WT02HL SUP-P8H-EPR 8 A
I
n
d
us
t
r
i
es
Co., Ltd.
R88D-WTA3H to
WT02H
SUP-P5H-EPR 5 A
250 V 0.6 mA (at 250 Vrms, 60 Hz) Okaya
Electric
Industries
R88D-WT04H SUP-P8H-EPR 8 A
I
n
d
us
t
r
i
es
Co., Ltd.
R88D-WT05H FN351-8/29 8 A
440 V
1.9 mA (at 400 Vrms, 50 Hz)
Schaffner
R88D-WT08H to
WT15H
FN351-16/29 16 A 1.9 mA (at 400 Vrms, 50 Hz)
R88D-WT20H FN351-25/33 25 A 28 mA (at 400 Vrms, 50 Hz)
R88D-WT30H FN351-36/33 36 A 28 mA (at 400 Vrms, 50 Hz)
R88D-WT50H to
WT60H
FMAC-0934-5010 50 A
480 V
5 mA (at 440 Vrms, 50 Hz)
TIMONTA
R88D-WT75H FMAC-0953-6410 64 A 5 mA (at 440 Vrms, 50 Hz)
R88D-WT150H FS5559-150-35 150 A 1.8 mA (at 480 Vrms, 50 Hz) Schaffner
Note The leakage currents shown for Schaffner noise filters are the values for when a three-phase
power supply uses a Y connection. The leakage current will be greater for a X connection.
External Dimensions
w SUP-PjH-EPR Noise Filters (by Okaya Electric Industries Co., Ltd.)
Two, 4.8 dia.
Five, M4
System Design and Installation
Chapter 3
