2-5
• Power Cable for 3,000-r/min Flat-style Servomotors
Specifications Model
p
Without brake With brake
100 to
750 W
3 m R88A-CAWA003S R88A-CAWA003B
750 W
5 m R88A-CAWA005S R88A-CAWA005B
10 m R88A-CAWA010S R88A-CAWA010B
15 m R88A-CAWA015S R88A-CAWA015B
20 m R88A-CAWA020S R88A-CAWA020B
30 m R88A-CAWA030S R88A-CAWA030B
40 m R88A-CAWA040S R88A-CAWA040B
50 m R88A-CAWA050S R88A-CAWA050B
1.5 kW
3 m R88A-CAWB003S R88A-CAWB003B
5 m R88A-CAWB005S R88A-CAWB005B
10 m R88A-CAWB010S R88A-CAWB010B
15 m R88A-CAWB015S R88A-CAWB015B
20 m R88A-CAWB020S R88A-CAWB020B
30 m R88A-CAWB030S R88A-CAWB030B
40 m R88A-CAWB040S R88A-CAWB040B
50 m R88A-CAWB050S R88A-CAWB050B
• Power Cable for 1,000-r/min Servomotors
Specifications Model
p
Without brake With brake
300 to
900 W
3 m R88A-CAWC003S R88A-CAWC003B
900 W
5 m R88A-CAWC005S R88A-CAWC005B
10 m R88A-CAWC010S R88A-CAWC010B
15 m R88A-CAWC015S R88A-CAWC015B
20 m R88A-CAWC020S R88A-CAWC020B
30 m R88A-CAWC030S R88A-CAWC030B
40 m R88A-CAWC040S R88A-CAWC040B
50 m R88A-CAWC050S R88A-CAWC050B
1.2 to 3 kW
3 m R88A-CAWD003S R88A-CAWD003B
5 m R88A-CAWD005S R88A-CAWD005B
10 m R88A-CAWD010S R88A-CAWD010B
15 m R88A-CAWD015S R88A-CAWD015B
20 m R88A-CAWD020S R88A-CAWD020B
30 m R88A-CAWD030S R88A-CAWD030B
40 m R88A-CAWD040S R88A-CAWD040B
50 m R88A-CAWD050S R88A-CAWD050B
4 kW
(S t )
3 m R88A-CAWE003S R88A-CAWE003B
(See note.)
5 m R88A-CAWE005S R88A-CAWE005B
10 m R88A-CAWE010S R88A-CAWE010B
15 m R88A-CAWE015S R88A-CAWE015B
20 m R88A-CAWE020S R88A-CAWE020B
30 m R88A-CAWE030S R88A-CAWE030B
40 m R88A-CAWE040S R88A-CAWE040B
50 m R88A-CAWE050S R88A-CAWE050B
5.5 kW
(S t )
3 m R88A-CAWF003S R88A-CAWE003B
(See note.)
5 m R88A-CAWF005S R88A-CAWE005B
10 m R88A-CAWF010S R88A-CAWE010B
15 m R88A-CAWF015S R88A-CAWE015B
20 m R88A-CAWF020S R88A-CAWE020B
30 m R88A-CAWF030S R88A-CAWE030B
40 m R88A-CAWF040S R88A-CAWE040B
50 m R88A-CAWF050S R88A-CAWE050B
Note For 4-kW and 5.5-kW Servomotors, there are separate
connectors for power and brakes. For that reason, when a
Servomotor with a brake is used, it will require both a Power
Cable for a Servomotor without a brake (i.e., R88A-CAWE-
jS or R88A-CAWFjS) and a Power Cable for a Servomo-
tor with a brake (i.e., R88A-CAWEjB). The Power Cable
for a Servomotor with a Brake is for brake line wiring only
(2-core).
Standard Models and Specifications Chapter 2
