2-10
• 1,500-r/min Servomotors
Specifications
Model
p
With incremental encoder With absolute encoder
Straight shaft without
key
Straight shaft with key Straight shaft without
key
Straight shaft with key
Without
bk
200 V
450 W --- --- R88M-W45015T R88M-W45015T-S2
brake
850 W --- --- R88M-W85015T R88M-W85015T-S2
1.3 kW --- --- R88M-W1K315T R88M-W1K315T-S2
1.8 kW --- --- R88M-W1K815T R88M-W1K815T-S2
2.9 kW --- --- R88M-W2K915T R88M-W2K915T-S2
4.4 kW --- --- R88M-W4K415T R88M-W4K415T-S2
5.5 kW --- --- R88M-W5K515T R88M-W5K515T-S2
7.5 kW --- --- R88M-W7K515T R88M-W7K515T-S2
11 kW --- --- R88M-W11K015T R88M-W11K015T-S2
15 kW --- --- R88M-W15K015T R88M-W15K015T-S2
With
bk
200 V
450 W --- --- R88M-W45015T-B R88M-W45015T-BS2
brake
850 W --- --- R88M-W85015T-B R88M-W85015T-BS2
1.3 kW --- --- R88M-W1K315T-B R88M-W1K315T-BS2
1.8 kW --- --- R88M-W1K815T-B R88M-W1K815T-BS2
2.9 kW --- --- R88M-W2K915T-B R88M-W2K915T-BS2
4.4 kW --- --- R88M-W4K415T-B R88M-W4K415T-BS2
5.5 kW --- --- R88M-W5K515T-B R88M-W5K515T-BS2
7.5 kW --- --- R88M-W7K515T-B R88M-W7K515T-BS2
11 kW --- --- R88M-W11K015T-B R88M-W11K015T-BS2
15 kW --- --- R88M-W15K015T-B R88M-W15K015T-BS2
Standard Models and Specifications Chapter 2
