2-14
• 1,000-r/min Servomotors
Specifications Basic model
Gear (deceleration rate)
p
1/5 1/9 1/11 1/20 1/21 1/29 1/33 1/45
-G05BJ -G09BJ -G11BJ -G20BJ -G21BJ -G29BJ -G33BJ -G45BJ
200 V
300 W R88M-W30010H/T
n n n n n
600 W R88M-W60010H/T
n n n n n
900 W R88M-W90010H/T
n n n n n
1.2 kW R88M-W1K210H/T
n n n n n
2 kW R88M-W2K010H/T
n n n
3 kW R88M-W3K010H/T
n n
4 kW R88M-W4K010H/T
5.5 kW R88M-W5K510H/T
• 1,500-r/min Servomotors
Specifications Basic model
Gear (deceleration rate)
p
1/5 1/9 1/11 1/20 1/21 1/29 1/33 1/45
-G05BJ -G09BJ -G11BJ -G20BJ -G21BJ -G29BJ -G33BJ -G45BJ
200 V
450 W R88M-W45015T
n n n n n
850 W R88M-W85015T
n n n n n
1.3 kW R88M-W1K315T
n n n n n
1.8 kW R88M-W1K815T
n n n n
2.9 kW R88M-W2K915T
n n n
4.4 kW R88M-W4K415T
n n
5.5 kW R88M-W5K515T
7.5 kW R88M-W7K515T
11 kW R88M-W11K015T
15 kW R88M-W15K015T
D Combination Table for Servomotors with Economy Gears
Economy Gears are low-cost gears, with a maximum backlash of 45 degrees. The shaft is a straight
shaft with key. Models without keys are not available.
Note 1. The 1,000-r/min and 1,500-r/min Servomotors cannot be combined with Economy Gears.
Note 2. A check mark in a box indicates that the two models can be combined. If the box is unchecked,
then the models cannot be combined.
Standard Models and Specifications Chapter 2
