2-16
D Servomotors with Standard Gears (Straight Shaft with Key)
• 3,000-r/min Servomotors
Specifications
Model
Spec ca o s
With incremental encoder With absolute encoder
Without brake With brake Without brake With brake
100 V 30 W
1/5 R88M-W03030L-G05BJ R88M-W03030L-BG05BJ R88M-W03030S-G05BJ R88M-W03030S-BG05BJ
00
30
1/9 R88M-W03030L-G09BJ R88M-W03030L-BG09BJ R88M-W03030S-G09BJ R88M-W03030S-BG09BJ
1/21 R88M-W03030L-G21BJ R88M-W03030L-BG21BJ R88M-W03030S-G21BJ R88M-W03030S-BG21BJ
1/33 R88M-W03030L-G33BJ R88M-W03030L-BG33BJ R88M-W03030S-G33BJ R88M-W03030S-BG33BJ
50 W
1/5 R88M-W05030L-G05BJ R88M-W05030L-BG05BJ R88M-W05030S-G05BJ R88M-W05030S-BG05BJ
50
1/9 R88M-W05030L-G09BJ R88M-W05030L-BG09BJ R88M-W05030S-G09BJ R88M-W05030S-BG09BJ
1/21 R88M-W05030L-G21BJ R88M-W05030L-BG21BJ R88M-W05030S-G21BJ R88M-W05030S-BG21BJ
1/33 R88M-W05030L-G33BJ R88M-W05030L-BG33BJ R88M-W05030S-G33BJ R88M-W05030S-BG33BJ
100 W
1/5 R88M-W10030L-G05BJ R88M-W10030L-BG05BJ R88M-W10030S-G05BJ R88M-W10030S-BG05BJ
00
1/11 R88M-W10030L-G11BJ R88M-W10030L-BG11BJ R88M-W10030S-G11BJ R88M-W10030S-BG11BJ
1/21 R88M-W10030L-G21BJ R88M-W10030L-BG21BJ R88M-W10030S-G21BJ R88M-W10030S-BG21BJ
1/33 R88M-W10030L-G33BJ R88M-W10030L-BG33BJ R88M-W10030S-G33BJ R88M-W10030S-BG33BJ
200 W
1/5 R88M-W20030L-G05BJ R88M-W20030L-BG05BJ R88M-W20030S-G05BJ R88M-W20030S-BG05BJ
00
1/11 R88M-W20030L-G11BJ R88M-W20030L-BG11BJ R88M-W20030S-G11BJ R88M-W20030S-BG11BJ
1/21 R88M-W20030L-G21BJ R88M-W20030L-BG21BJ R88M-W20030S-G21BJ R88M-W20030S-BG21BJ
1/33 R88M-W20030L-G33BJ R88M-W20030L-BG33BJ R88M-W20030S-G33BJ R88M-W20030S-BG33BJ
200 V 30 W
1/5 R88M-W03030H-G05BJ R88M-W03030H-BG05BJ R88M-W03030T-G05BJ R88M-W03030T-BG05BJ
00
30
1/9 R88M-W03030H-G09BJ R88M-W03030H-BG09BJ R88M-W03030T-G09BJ R88M-W03030T-BG09BJ
1/21 R88M-W03030H-G21BJ R88M-W03030H-BG21BJ R88M-W03030T-G21BJ R88M-W03030T-BG21BJ
1/33 R88M-W03030H-G33BJ R88M-W03030H-BG33BJ R88M-W03030T-G33BJ R88M-W03030T-BG33BJ
50 W
1/5 R88M-W05030H-G05BJ R88M-W05030H-BG05BJ R88M-W05030T-G05BJ R88M-W05030T-BG05BJ
50
1/9 R88M-W05030H-G09BJ R88M-W05030H-BG09BJ R88M-W05030T-G09BJ R88M-W05030T-BG09BJ
1/21 R88M-W05030H-G21BJ R88M-W05030H-BG21BJ R88M-W05030T-G21BJ R88M-W05030T-BG21BJ
1/33 R88M-W05030H-G33BJ R88M-W05030H-BG33BJ R88M-W05030T-G33BJ R88M-W05030T-BG33BJ
100 W
1/5 R88M-W10030H-G05BJ R88M-W10030H-BG05BJ R88M-W10030T-G05BJ R88M-W10030T-BG05BJ
00
1/11 R88M-W10030H-G11BJ R88M-W10030H-BG11BJ R88M-W10030T-G11BJ R88M-W10030T-BG11BJ
1/21 R88M-W10030H-G21BJ R88M-W10030H-BG21BJ R88M-W10030T-G21BJ R88M-W10030T-BG21BJ
1/33 R88M-W10030H-G33BJ R88M-W10030H-BG33BJ R88M-W10030T-G33BJ R88M-W10030T-BG33BJ
200 W
1/5 R88M-W20030H-G05BJ R88M-W20030H-BG05BJ R88M-W20030T-G05BJ R88M-W20030T-BG05BJ
00
1/11 R88M-W20030H-G11BJ R88M-W20030H-BG11BJ R88M-W20030T-G11BJ R88M-W20030T-BG11BJ
1/21 R88M-W20030H-G21BJ R88M-W20030H-BG21BJ R88M-W20030T-G21BJ R88M-W20030T-BG21BJ
1/33 R88M-W20030H-G33BJ R88M-W20030H-BG33BJ R88M-W20030T-G33BJ R88M-W20030T-BG33BJ
400 W
1/5 R88M-W40030H-G05BJ R88M-W40030H-BG05BJ R88M-W40030T-G05BJ R88M-W40030T-BG05BJ
00
1/11 R88M-W40030H-G11BJ R88M-W40030H-BG11BJ R88M-W40030T-G11BJ R88M-W40030T-BG11BJ
1/21 R88M-W40030H-G21BJ R88M-W40030H-BG21BJ R88M-W40030T-G21BJ R88M-W40030T-BG21BJ
1/33 R88M-W40030H-G33BJ R88M-W40030H-BG33BJ R88M-W40030T-G33BJ R88M-W40030T-BG33BJ
750 W
1/5 R88M-W75030H-G05BJ R88M-W75030H-BG05BJ R88M-W75030T-G05BJ R88M-W75030T-BG05BJ
50
1/11 R88M-W75030H-G11BJ R88M-W75030H-BG11BJ R88M-W75030T-G11BJ R88M-W75030T-BG11BJ
1/21 R88M-W75030H-G21BJ R88M-W75030H-BG21BJ R88M-W75030T-G21BJ R88M-W75030T-BG21BJ
1/33 R88M-W75030H-G33BJ R88M-W75030H-BG33BJ R88M-W75030T-G33BJ R88M-W75030T-BG33BJ
1 kW
1/5 R88M-W1K030H-G05BJ R88M-W1K030H-BG05BJ R88M-W1K030T-G05BJ R88M-W1K030T-BG05BJ
1/9 R88M-W1K030H-G09BJ R88M-W1K030H-BG09BJ R88M-W1K030T-G09BJ R88M-W1K030T-BG09BJ
1/20 R88M-W1K030H-G20BJ R88M-W1K030H-BG20BJ R88M-W1K030T-G20BJ R88M-W1K030T-BG20BJ
1/29 R88M-W1K030H-G29BJ R88M-W1K030H-BG29BJ R88M-W1K030T-G29BJ R88M-W1K030T-BG29BJ
1/45 R88M-W1K030H-G45BJ R88M-W1K030H-BG45BJ R88M-W1K030T-G45BJ R88M-W1K030T-BG45BJ
1.5 kW
1/5 R88M-W1K530H-G05BJ R88M-W1K530H-BG05BJ R88M-W1K530T-G05BJ R88M-W1K530T-BG05BJ
5
1/9 R88M-W1K530H-G09BJ R88M-W1K530H-BG09BJ R88M-W1K530T-G09BJ R88M-W1K530T-BG09BJ
1/20 R88M-W1K530H-G20BJ R88M-W1K530H-BG20BJ R88M-W1K530T-G20BJ R88M-W1K530T-BG20BJ
1/29 R88M-W1K530H-G29BJ R88M-W1K530H-BG29BJ R88M-W1K530T-G29BJ R88M-W1K530T-BG29BJ
1/45 R88M-W1K530H-G45BJ R88M-W1K530H-BG45BJ R88M-W1K530T-G45BJ R88M-W1K530T-BG45BJ
Standard Models and Specifications Chapter 2
