22 Frequency inverters
A Line filters
A Input AC reactors
A DC reactors
A Output AC reactors
Note: This table corresponds with HD rating. When ND is used, please choose the reactor for the next size inverter.
A Chokes
400 V
Line filter (Schaffner)
Model
Q2A-A
Filter style Reference Current Quantity
4002 / 4004 / 4005 / 4007 Footprint type Q2-FIA4010-SE 10 A 1
4009 / 4012 Q2-FIA4020-SE 20 A 1
4018 / 4023 Q2-FIA4035-SE 35 A 1
4031 / 4038 Q2-FIA4050-SE 50 A 1
4044 / 4060 / 4075 Book type Q2-FIA4080-SE 80 A 1
4089 Q2-FIA4100-SE 100 A 1
4103 / 4140 / 4168 Q2-FIA4170-SE 170 A 1
4208 / 4250 / 4296 / 4371 / 4389 Busbar termination type Q2-FIA4410-SE 410 A 1
4453 / 4568 Q2-FIA4600-SE 600 A 1
4675 Q2-FIA4410-SE 410 A 2
400 V
Model
Q2A-A
Input AC reactor
Model
Q2A-A
Input AC reactor
4002 AX-RAI07700042-DE 4060 / 4075 AX-RAI00290780-DE
4004 AX-RAI07700050-DE 4089 / 4103 AX-RAI00191150-DE
4005 AX-RAI03500090-DE 4140 / 4168 AX-RAI00111850-DE
4007 AX-RAI03500100-DE 4208 / 4250 AX-RAI00072700-DE
4009 / 4012 AX-RAI01300170-DE 4296 AX-RAI00043350-DE
4018 / 4023 / 4031 AX-RAI00740335-DE 4371 / 4389 AX-RAI00034500-DE
4038 / 4044 AX-RAI00360500-DE 4453 AX-RAI00025350-DE
400 V
Model
Q2A-A
DC Reactor
Model
Q2A-A
DC Reactor
4002 / 4004 AX-RC43000020-DE 4018 AX-RC03350219-DE
4005 AX-RC10100069-DE 4023 AX-RC02330307-DE
4007 / 4009 AX-RC06400116-DE 4031 / 4038 AX-RC01750430-DE
4012 AX-RC04410167-DE -
400 V
Model
Q2A-A
Output AC reactor
Model
Q2A-A
Output AC reactor
4002 AX-RAO16300038-DE 4075 AX-RAO00680900-DE
4004 AX-RAO11800053-DE 4089 / 4103 AX-RAO00531100-DE
4005 AX-RAO07300080-DE 4140 AX-RAO00401490-DE
4007 / 4009 AX-RAO04600110-DE 4168 AX-RAO00331760-DE
4012 AX-RAO03600160-DE 4208 AX-RAO00262170-DE
4018 AX-RAO02500220-DE 4250 AX-RAO00212600-DE
4023 AX-RAO02000320-DE 4296 AX-RAO00173250-DE
4031 AX-RAO01650400-DE 4371 / 4389 AX-RAO00134440-DE
4038 / 4044 AX-RAO01300480-DE 4453 AX-RAO00115250-DE
4060 AX-RAO00800750-DE -
Model Diameter Description
AX-FER2102-RE 21
For 2.2 KW motors or below
AX-FER2515-RE 25
For 15 KW motors or below
AX-FER5045-RE 50
For 45 KW motors or below
AX-FER6055-RE 60
For 55 KW motors or below
I175E-EN-01+Q2A+Datasheet.fm Seite 22 Montag, 26. März 2018 3:18 15
