Chapter 3: Installation
4X M3 x 6MM
21.6
16.0
120.9
16.2
4X 40356-00001
120.9
29.5
391.8
378.6
24.9
R3.6
12.1
24.1
Figure 3-3. Table-Mounting the SmartController EX Motion Controller (Units in mm)
Stack-Mounting Components
To stack-mount the SmartController EX motion controller and a compatible unit, such as a
SmartVision MX vision controller, install two brackets on each side of the units, as shown in
the following figure. These brackets are supplied with compatible units.
11069-000 Rev. H SmartController EX User's Guide 19
