Chapter 4: Operation
+
–
220
2.2K
26LS33
SmartController EX
2.2K
–
+
A–
A+
5V
B+
B–
I+
I–
+
–
A–
A+
B+
B–
I+
I–
5 V at 800 mA
(1 A max.)
220
2.2K
26LS33
2.2K
5V
1
2
3
3
Figure 4-7. Belt Encoder Typical Input Circuit
Table 4-16. Belt Encoder Typical Input Descriptions
Item Description
1 Encoder 1
2 Encoder 2
3 Shield
