Revision History
A manual revision code appears as a suffix to the catalog number on the front cover of the manual.
Cat. No. W111-E1-10
Revision code
The following table outlines the changes made to the manual during each revision. Page numbers refer to the
previous version.
Revision code Date Revised content
6 July 1989 Corrections
to pages: 3, 6, 16 to 18, 21, 23, 26, 27, 31, 32, 33, 41, 51, 52, 53, 57,
58,
and 60.
7 February 1990 Entire manual reorganized and reproduced.
8 October 1990 Revision
of text and inclusion of new product information (C200H-CPU1
1-E, SYS
-
MAC NET, SYSMAC LINK, C200H-OC225, and C200H-OD212)
Corrections to pages: 7, 10, 12, 13, 15, 16, 23, 27, 28, 34 to 39, 61, 63, 64, 82,
85,
94, 97 to 100, 103, 104.
8A May 1991 Pages 33 to 38: Completely redone.
Page 102: Backplane model numbers revised.
Page 103: BC031-V1 and BC101-V1 added to note at bottom of page.
Page 104: Microwave ID Sensor and Analog I/O Units added.
Page 110: Terminal Resistor and Power Supply Adapter model numbers re-
vised.
The manuals has also been reformatted, changing page numbers slightly.
8B May 1992 Page 7: PC Operation Flowchart redone.
Page 27: The section reference in the second line corrected to
Section 2-6
Memory Packs
.
Page 28: “Optical Fiber Cable” in the lower left corner corrected to “Optical
Fiber Cable or Wire Cable”.
Pages 113 to 128: The following instructions are missing from
Appendix E
Programming Instructions
: LMSG(47), TERM(48), SYS(49), CMPL(60),
CTW(63), WTC(64), HTS(65), STH(66), VAL(69), SEND(90), and RECV(98).
(These instructions were originally added in revision 8, but inadvertently
omitted from revision 8A.)
8C December 1993 Multipoint I/O changed to High-density I/O throughout the manual. Scan time
changed to cycle time throughout the manual.
Page 10: Model number corrections made in the first paragraph of
CPU
.
Page 28: Reference corrected for SYSMAC NET Link Unit and SYSMAC LINK
Unit.
Page 32: T
able updated.
Page 33: Note added, 1.4 V corrected to 1.4 A in the top table.
Pages 34, 35:
Models added and updated.
Page 37: Calculation of power consumption corrected.
Page 38: I/O Unit Cover description added.
Page 42: Ambient conditions added.
Page 79: “8 A/Unit” in Terminal Connections changed to “16 A/Unit”.
Page 82: Max. switching capacity changed.
Page 92: B7A Interface Unit specifications added.
Pages 97 to 105: Appendix C completely updated.
