Appendix BSpecifications
167
Peripheral Unit C
CPU21-E/23-E CPU31-E
Programming Console 148 173
Other peripheral device 160 185
B-shape I/O Unit 145 145
E-shape I/O Unit 138 138
Standard I/O Units The dimensions shown below are for the two shapes of Standard I/O Units mentioned
throughout these specifications.
10-terminal Terminal Block (A-shape I/O Units)
145
128
x
x
x
x
x
x
x
x
35
130
19-terminal Terminal Block (B-shape I/O Units)
Backplane
