Omron SYSMAC C200H Installation Guide

73
Appendix A
Standard Models
C200H Racks
Name Specifications Model number
Backplane (same for all Racks)
10 slots C200H-BC101-V2
8 slots C200H-BC081-V2
5 slots C200H-BC051-V2
3 slots C200H-BC031-V2
CPU Rack CPU Units w/built-in power supply (100 to 120/200 to 240 VAC);
Output current: 4.6 A (3.2 A to I/O Units)
C200H-CPU21-E
w/built-in power supply (24 VDC);
Output current: 3 A (1.6 A to I/O Units)
C200H-CPU23-E
w/built-in power supply (100 to 120/200 to 240 VAC);
Output current: 4.6 A (3.0 A to I/O Units);
Can support SYSMAC NET Link/SYSMAC LINK Units.
C200H-CPU31-E
Memory Units CMOS-RAM Units; battery back-up UM: 3K words;
DM: 1K words
C200H-MR431
UM: 7K words;
DM: 1K words
C200H-MR831
CMOS-RAM Units; battery back-up;
with clock
UM: 3K words;
DM: 1K words
C200H-MR433
UM: 7K words;
DM: 1K words
C200H-MR833
CMOS-RAM Units; capacitor back-up UM: 3K words;
DM: 1K words
C200H-MR432
UM: 7K words;
DM: 1K words
C200H-MR832
EPROM Unit
(EPROM ordered separately)
UM: 7K words;
DM: 1K words
C200H-MP831
EEPROM Units UM: 3K words;
DM: 1K words
C200H-ME431
UM: 7K words;
DM: 1K words
C200H-ME831
EEPROM Units with clock UM: 3K words;
DM: 1K words
C200H-ME432
UM: 7K words;
DM: 1K words
C200H-ME832
EPROM 27128; 150 ns; write voltage: 12.5 V ROM-ID-B
Expansion I/O Power Supply 100 to 120/200 to 240 VAC (selectable) C200H-PS221
I/O Racks Units
24 VDC C200H-PS211
I/O Connecting 30 cm C200H-CN311
Cables (max. total
70 cm C200H-CN711
length: 12 m)
2 m C200H-CN221
5 m C200H-CN521
10 m C200H-CN131
