Omron SYSMAC C200H Installation Guide

Standard Models Appendix A
74
C200H Standard I/O Units
Name Specifications Model number
Input Units AC Input Units 8 pts 100 to 120 VAC C200H-IA121
16 pts 100 to 120 VAC C200H-IA122/IA122V
8 pts 200 to 240 VAC C200H-IA221
16 pts 200 to 240 VAC C200H-IA222/IA222V
DC Input Units 8 pts No-voltage contact; NPN C200H-ID001
8 pts No-voltage contact; PNP C200H-ID002
8 pts 12 to 24 VDC C200H-ID211
16 pts 24 VDC C200H-ID212
AC/DC Input Units 8 pts 12 to 24 VAC/DC C200H-IM211
16 pts 24 VAC/DC C200H-IM212
Output
Relay Output Units 8 pts 2 A, 250 VAC/24 VDC (For resistive loads) C200H-OC221
Units
12 pts 2 A, 250 VAC/24 VDC (For resistive loads) C200H-OC222
16 pts 2 A, 250 VAC/24 VAC (For resistive loads) C200H-OC225
1, 2
5 pts 2 A, 250 VAC/24 VDC (For resistive loads)
Independent commons
C200H-OC223
8 pts 2 A, 250 VAC/24 VDC (For resistive loads)
Independent commons
C200H-OC224
Triac Output Units 8 pts 1 A, 120 VAC C200H-OA121-E
8 pts 1.2 A, 120 VAC C200H-OA122-E
8 pts 1 A, 250 VAC C200H-OA221
8 pts 1.2 A 250 VAC C200H-OA223
12 pts 0.3 A, 250 VAC C200H-OA222V
12 pts 0.5 A, 250 VAC C200H-OA224
Transistor Output
8 pts 1 A, 12 to 48 VDC C200H-OD411
Units
12 pts 0.3 A, 24 VDC C200H-OD211
16 pts 0.3 A, 24 VDC C200H-OD212
1
8 pts 2.1 A, 24 VDC C200H-OD213
8 pts 0.8 A, 24 VDC; source type (PNP); with load
short protection
C200H-OD214
8 pts 0.3 A, 5 to 24 VDC; source type (PNP) C200H-OD216
12 pts 0.3 A, 5 to 24 VDC; source type (PNP) C200H-OD217
12 pts 1 A, 24 VDC; source type (PNP); with load
short protection
C200H-OD21A
Analog Timer
Unit
4 timer
pts
0.1 to 1 s, 1 to 10 s, 10 to 60 s, or 1 min to
10 min (switchable)
C200H-TM001
Variable Resistor
Connector
(Related Product)
Connector with lead wire (2 m) for 1 external
resistor
C4K-CN223
Standard B7A Interface Units
16 input
pts
Connects to B7A Link Terminals.
C200H-B7AI1
16 out-
put pts
C200H-B7AO1
1
Note 1. C200H-OD212/OD21A Transistor Output Unit, C200H-OC225 Contact Output Unit and C200H-B7AO1
B7A Interface Unit must be mounted to either a C200H-BC031-V1/V2, C200H-BC051-V1/V2, C200H-
BC081-V1/V2, or C200H-BC101-V1/V2 Backplane.
2. The C200H-OC225 might overheat if more than 8 outputs are turned ON simultaneously.
