Appendix AStandard Models
75
C200H Group-2 High-density I/O Units
Name Specifications Model number
DC Input Unit 64 pts 12 VDC C200H-ID111
32 pts. 24 VDC C200H-ID216
64 pts. 24 VDC C200H-ID217
Transistor Output
32 pts. 16 mA 4.5 VDC to 100 mA 26.4 VDC C200H-OD218
Units
64 pts. 16 mA 4.5 VDC to 100 mA 26.4 VDC C200H-OD219
C200H Group-2 B7A Interface Units
Name Specifications Model number
Group-2 B7A Interface Units
32 input pts
Connects to B7A Link
C200H-B7A12
32 output pts
Terminals.
C200H-B7A02
16 input pts and 16 output points C200H-B7A21
32 input pts and 32 output points C200H-B7A22
C200H Special I/O Units
All of the following are classified as Special I/O Units except for the ASCII Unit, which is an Intelligent I/O Unit.
Name Specifications Model number
High- DC Input
32 pts 5 VDC (TTL inputs); with high-speed input function C200H-ID501
density I/O
Units
Units
32 pts 24 VDC; with high-speed inputs C200H-ID215
Transistor 32 pts 0.1 A, 24 VDC (usable as 128-point dynamic output unit) C200H-OD215
Output Units
32 pts 35 mA, 5 VDC (TTL outputs) (usable as 128-point dy-
namic output unit)
C200H-OD501
DC Input/
Transistor
Output Units
16 input/
16 output pts
12-VDC inputs; with high-speed input function
0.1 A , 12-VDC outputs (usable as 128-point dynamic in-
put unit)
C200H-MD115
16 input/
16 output pts
24-VDC inputs; with high-speed input function
0.1 A , 24-VDC outputs (usable as 128-point dynamic in-
put unit)
C200H-MD215
16 input/
16 output pts
5 VDC (TTL inputs); with high speed input function 35
mA, 5 VDC Output (TTL outputs) (usable as 128-point
dynamic input unit)
C200H-MD501
Analog I/O Analog Input 4 to 20 mA, 1 to 5/0 to 10 V; 4 inputs C200H-AD001
Units Units
4 to 20 mA, 1 to 5/0 to 10/–10 to 10 V; 8 inputs C200H-AD002
Analog 4 to 20 mA, 1 to 5/0 to 10 V; 2 outputs C200H-DA001
Output Unit
4 to 20 mA, –10 to 10 V; 4 outputs C200H-DA002
Temperature Sensor Units Thermocouple (K(CA) or J(IC)) (switchable); 4 inputs C200H-TS001
Thermocouple (K(CA) or L(Fe-CuNi)) (switchable); 4 inputs C200H-TS002
Platinum resistance thermometer (JPt) (switchable), DIN standards;
4 inputs
C200H-TS101
Platinum resistance thermometer (Pt) (switchable); 4 inputs C200H-TS102
Temperature Control Units Thermocou- Transistor output C200H-TC001
ple
Voltage output C200H-TC002
Current output C200H-TC003
Platinum re- Transistor output C200H-TC101
sistance
Voltage output C200H-TC102
thermome-
ter
Current output C200H-TC103
