Standard Models Appendix A
76
Name Model numberSpecifications
Heat/Cool Temperature Thermocou- Transistor output C200H-TV001
Control Units ple
Voltage output C200H-TV002
Current output C200H-TV003
Platinum re- Transistor output C200H-TV101
sistance
Voltage output C200H-TV102
thermome-
ter
Current output C200H-TV103
PID Control Units Transistor output (open collector);
4 to 20 mA/1 to 5 V/0 to 5V/0 to 10 V inputs (selectable)
C200H-PID01
Voltage output;
4 to 20 mA/1 to 5 V/0 to 5V/0 to 10 V inputs (selectable)
C200H-PID02
Current output;
4 to 20 mA/1 to 5 V/0 to 5V/0 to 10 V inputs (selectable)
C200H-PID03
Position Control Units 1 axis Pulse output; speeds: 1 to 100,000 pps C200H-NC111
1 axis Pulse output; directly connectable to servomotor driver;
compatible with line driver; speeds: 1 to 250,000 pps
C200H-NC112
2 axis Pulse output; 1 to 250,000 pps, 53 pts per axis C200H-NC211
Cam Positioner Unit Detects angles of rotation by means of a resolver and provides ON and
OFF outputs at specified angles. A maximum of 48 cam outputs (16 ex-
ternal outputs and 32 internal outputs) maximum are available.
C200H-CP114
High-speed Counter Units 1 axis Pulse input; counting speed: 50 kcps;
5 VDC/12 VDC/24 VDC
C200H-CT001-V1
1 axis Pulse input; counting speed: 75 kcps;
RS-422 line driver
C200H-CT002
2 axis Pulse input; counting speed: 75 kcps;
RS-422 line driver; 7-digit BCD
C200H-CT021
ASCII Unit 24K-byte RAM and 24K-byte EEPROM are built-in. C200H-ASC02
Connecting
Cable
RS-232C
For connecting the ASCII Unit to the FIT10 (9P/25P)
Cable length: 2 m
CV500-CN228
ID Sensor Units Local application, electromagnetic coupling C200H-IDS01-V1
Remote application, microwave transmissions C200H-IDS21
Read/Write Electromagnetic type V600-H series
Head
Microwave type V620-H series
Data Carrier SRAM type for V600-H series.
V600-DjjRjj
(see note)
EEPROM type for V600-H series.
V600-DjjPjj
Voice Unit 60 messages max.; message length: 32, 48, or 64 s (switchable) C200H-OV001
Connecting
Cable
RS-232C
For connecting the Voice Unit to the FIT10 (6P/25P)
Cable length: 2 m
C200H-CN224
Fuzzy Logic Unit Up to 8 inputs and 4 outputs. (I/O to and from specified data area words) C200H-FZ001
Note For Read/Write Head and Data Carrier combinations, refer to the V600 FA ID System R/W Heads and EE-
PROM Data Carriers Operation Manual and Supplement or V600 FA ID System R/W Heads and SRAM
Data Carriers Operation Manual and Supplement.
C200H Link Units
Name Specifications Model number
Host Link Units Rack-mounting C200H only APF/PCF C200H-LK101-PV1
RS-422 C200H-LK202-V1
RS-232C C200H-LK201-V1
CPU Unit-mounting C1000H/C2000H PCF 3G2A6-LK101-EV1
C500 APF/PCF 3G2A6-LK101-PEV1
