Omron SYSMAC C200H Installation Guide

Appendix AStandard Models
77
Name Model numberSpecifications
C200H RS-232C 3G2A6-LK201-EV1
C120 RS-422 3G2A6-LK202-EV1
PC Link Unit Single level: 32 Units
Multilevel: 16 Units
RS-485 C200H-LK401
Remote I/O Up to two per PC; connectable to up to 5
APF/PCF C200H-RM001-PV1
Master Units Slaves per PC total
Wired C200H-RM201
Remote I/O Slave Units 100 to 120/200 to 240 VAC (switchable) APF/PCF C200H-RT001-P
24 VDC C200H-RT002-P
100 to 120/200 to 240 VAC (switchable) Wired C200H-RT201
24 VDC C200H-RT202
Optional Products
Name Specifications Model number
I/O Unit Cover Cover for 10-pin terminal block C200H-COV11
Terminal Block Covers Short protection for 10-pin terminal block (package of 10 cov-
ers); 8 pts
C200H-COV02
Short protection for 19-pin terminal block (package of 10 cov-
ers); 12 pts
C200H-COV03
Connector Cover Protective cover for unused I/O Connecting Cable connectors C500-COV01
Space Unit Used for vacant slots C200H-SP001
Battery Set
For: C200H-MRj31/MRj33 RAM Memory Units
C200H-MEj32 EEPROM Memory Unit
C200H-CPU31-E CPU Unit
C200H-BAT09
Relay 24 VDC G6B-1174P-FD-US DC24
Backplane Insulation Plates For 10-slot Backplane C200H-ATTA1
For 8-slot Backplane C200H-ATT81
For 5-slot Backplane C200H-ATT51
For 3-slot Backplane C200H-ATT31
I/O Brackets For 5-slot Backplane C200H-ATT53
For 8-slot Backplane C200H-ATT83
For 3-slot Backplane C200H-ATT33
Memory Unit Lock Fitting To secure Memory Unit to CPU Unit C200H-ATT03
External Connectors
Solder terminal; 40 pin with connector cover
Straight type C500-CE401
Right-angle type C500-CE404
Solderless terminal (crimp-type); 40 pin with
Straight type C500-CE402
connector cover
Right-angle type C500-CE405
Pressure welded terminal; 40 pin C500-CE403
Solder terminal; 24 pin with connector cover C500-CE241
Solderless terminal; 24 pin with connector cover (crimp-type) C500-CE242
Pressure welded terminal; 24 pin C500-CE243
Note 1. When ordering, specify the model name (any component of which is not sold separately).
2. Order the pressfit tool from the manufacturer.
