Standard Models Appendix A
78
Optical Units
Name Specifications Model no.
Optical I/O
No-voltage Input Units 8 pts.
100 to 120 VAC
APF/PCF 3G5A2-ID001-PE
Units power supply
PCF 3G5A2-ID001-E
AC/DC Input Units 12 to 24 VAC/DC 8 pts. APF/PCF 3G5A2-IM211-PE
PCF 3G5A2-IM211-E
AC Input Units 100 to 120 VAC 8 pts. APF/PCF 3G5A2-IA121-PE
PCF 3G5A2-IA121-E
Relay Output Units 2A, 250 VAC/24 VDC
100 to 120/200 to
APF/PCF 3G5A2-OC221-PE
(w/relay socket) 8 pts.
240 VAC power
supply
PCF 3G5A2-OC221-E
Triac Output Units 1A, 100 to 120/200 to
240 VAC (w/built-in
APF/PCF 3G5A2-OA222-PE
surge killer) 8 pts. PCF 3G5A2-OA222-E
Repeater Units Connected between 32nd and 33rd Units
when connecting more than 33 Units in a
APF/PCF 3G5A2-RPT01-PE
Remote Subsystem; power supply: 85 to
250 VAC.
PCF 3G5A2-RPT01-E
Link Adapters
Name Specifications Model no.
Link Adapters 3 RS-422 connectors 3G2A9-AL001
3 optical connectors (APF/PCF) 3G2A9-AL002-PE
3 optical connectors (PCF) 3G2A9-AL002-E
1 connector each for APF/PCF, RS-422, and RS-232C 3G2A9-AL004-PE
1 connector each for PCF, RS-422, and RS-232C 3G2A9-AL004-E
1 connector each for APF/PCF and APF 3G2A9-AL005-PE
1 connector each for PCF and AGF 3G2A9-AL005-E
O/E converter; 1 connector for RS-485, 1 connector each for APF/PCF B500-AL007-PE
Used for on-line removal of FIT or SYSMAC NET Link Units from the
SYSMAC NET Link System, SYSMAC NET Optical Link Adapter 3
connectors for APF/PCF.
B700-AL001
DIN Products
Name Specifications Model number
DIN Track Mounting Bracket 1 set (2 included) C200H-DIN01
DIN Track Length: 50 cm; height: 7.3 cm PFP-50N
Length: 1 m; height: 7.3 cm PFP-100N
Length: 1 m; height: 16 mm PFP-100N2
End Plate --- PFP-M
Spacer --- PFP-S
