7. Connection Procedure
7.3.5. Transferring the Project Data
Transfer the project data to the PLC.
1
Select Programs on the project
workspace of CX-programmer,
and select Transfer - To PLC
from the PLC Menu.
2
Select the Program(s) Check
Box, Comments Check Box, and
Program index Check Box, and
click the OK Button.
*Transferring the I/O table and
Special Unit Setup is
unnecessary here because
they were transferred in
Sections 7.3.3 and 7.3.4.
*The Comments Check Box and
the Program index Check Box
may not be displayed
depending on the device type.
In such a case, select the
Program(s) Check Box only
and transfer the project data.
3
The dialog box on the right is
displayed. Click the Yes Button.
