77
I/O Memory Allocations Section 2-3
D32002 D32012 m+ 2 m + 12 15
Host
Link,
Serial
Gate-
way,
Proto-
col
macro,
No-
proto-
col
Send delay 0: Default (0 ms); 1: User-specified
00 to 14 Send delay (user-specified): 0 to 300 s (0 to 300,000 ms)
(0000 to 7530 hex; 0 to 30,000 decimal)
(Unit: 10 ms)
D32003 D32013 m + 3 m + 13 15 CTS control (see note 5) 0: No; 1:Yes
14 1:N/1:1 protocol setting (Unit Ver. 1.2 or later only)
1: 1:1 protocol; 0: 1:N protocol
If the Host Link compatible device mode is set to 0 to 2 hex
(mode A or B), the setting in this bit is invalid (fixed to 1:N Host
Links)
11 to 13 Reserved
08 to 10 Host Link compatible device mode (Unit Ver. 1.2 or later only)
0 hex: Default (mode A)
1 hex: Mode A (CS/CJ/C)
2 hex: Mode B (CVM1/CV)
3 hex: Mode C (C200H)
4 hex: Mode D (C500/120)
00 to 07 Host
Link
Host Link unit number (00 to 1F hex)
D32004 D32014 m + 4 m + 14 08 to 15 No-
proto-
col
Start code (00 to FF hex)
00 to 07 End code (00 to FF hex)
D32005 D32015 m + 5 m + 15 13 to 15 Reserved
12 Start code inclusion setting
0: No; 1: Yes
10 to 11 Reserved
08 to 09 End code inclusion setting
00: No (specify number of receive data bytes)
01: Yes
10: CR + LF specified
00 to 07 Number of receive data bytes
00 hex (default): 256 bytes
01 to FF hex: 1 to 255 bytes
D32006 D32016 m + 6 m + 16 03 to 15 Mod-
bus-
RTU
slave
Modbus-RTU slave address
01 to F7 hex: 1 to 247
00 to 02 1:N NT Links maximum unit number (0 to 7)
D32007 D32017 m + 7 m + 17 08 to 15
Serial
Gate-
way/
Proto-
col
macro
Response timeout monitoring time (Unit Ver. 1.2 or later only)
00 hex: 5 s (default)
01 to FF hex (1 to 255 decimal): 0.1 to 25.5 s
(Unit: 100 ms)
00 to 07
Proto-
col
macro
Serial Gateway send start timeout monitoring time (Unit Ver.
1.2 or later only)
00 hex: 5 s (default)
01 to FF hex (1 to 255 decimal): 0.1 to 25.5 s
(Unit: 100 ms)
Words Bit Setting contents
Board
(CS Series only)
Unit
(CS/CJ Series)
Port 1 Port 2 Port 1 Port 2
To Next Page
