Omron SYSMAC CJ1W-SCU41-V1

261
Basic Operating Procedure in No-protocol Mode Section 7-4
Bar Code Reader Connected with RS-232C
Serial Communications Unit/Board
9-pin D-sub (female)
V509-W012
Extension Cable
Serial Communications Unit/Board
100 VAC
82S-0305 +5 V
External Power Su
pp
l
y
V509-W012 Extension Cable
V520-RH21-6
Bar Code Reader
SG
+5 V
V520-RH21-6
Bar Code Reader
DIN 8p
Signal
FG
SD
RD
RS
CS
DR
ER
SG
Pin No.
1
2
3
4
5
7
8
9
Signal
SD
RD
RS
CS
ER
SG
+5 V
Pin No.
1
2
3
4
6
7
8
