398
C-mode (Host Link) Command Master Appendix C
Receive Data Word Allocation (4th Operand of PMCR(260))
Note The read data from the end code area (+1 word, rightmost byte) is stored for responses without end
codes.
User-specified Send/Receive Command without Conversion
(Sequence No. 701 (Hex 02BD))
Sends the text data for the specified C-mode command to the specified Host Link Unit without converting into
ASCII. The response is stored starting from the specified word without converting into hexadecimal.
Send Data Word Allocation (3rd Operand of PMCR(260))
Offset Contents (data format) Data
+0
Number of receive data words 0003 to 00FA hex (3 to 250 decimal)
+1
(Undefined) End code
(2 digits hex)
The end code is stored in hexadecimal.
+2
Read data (4 digits hex) The read data is converted into hexa-
decimal stored.
Read data
Receive data
storage words
Number of receive data words
+0
+1
+2
(Undefined)
End code
Offset Contents (data format) Data
+0
Number of send data words 0004 to 0040 hex (4 to 64 decimal)
+1
(Undefined) Host Link unit
No.
(2 digits BCD)
00 to 31
+2
C-mode command code Specify the C-mode command code in
ASCII (e.g., RR is specified as 5252
hex.)
+3
Number of send bytes Specify the number of send bytes for
the communications line.
0000 to 007A hex (0 to 122 decimal)
Note: The text data is converted into
ASCII on the communications line, so
specify twice the number of bytes of
text data bytes in S+4 onwards.
+4
Text Specify the text that corresponds to the
command. The specified hexadecimal
data will be converted into ASCII and
sent.
+0
+1
+2
+3
+4
First word of
send data
Tex t
Number of send data words
(Undefined) Host Link unit No.
Number of send bytes
C-mode command code
